Product Dimensions 8.25"h x 36"w x 20.06"d
A perfect balance of modern style and high performances: cooking surface cleverly hides a powerful extraction system. The linear surface guarantees the freedom of movement with pots, preserving the easy cleaning advantage of the traditional induction hobs.Read More
Elica first extraction hob with the suction heart completely invisible that can be activated with a simple switch.
Thanks to Airmatic technology, NikolaTesla Switch is able to automatically adjust the extraction speed, thus optimising power consumption and performance. The control interface is intuitive and easy to use thanks to a specific slider for each zone and is totally invisible in standby mode, to be discreet and elegant.
Grease and high performance regenerable odor filters can be removed from the top without any effort, in the same way it is possible to access inner part to clean from accidentally leak out of the pots. In addition a special valve allows the discharge of any spilled liquid, to ensure maximum hygiene to your kitchen.
Fits seamlessly into any design concept for your kitchen. Elica’s aspiration cooktops have been designed to guarantee maximum installation flexibility, leaving enough space for undercabinet storage thanks to the movable ducting.
General Specs | |
| Color | Black |
| Appliance Fit Width (cm.) | 91 |
| Element Type | Induction |
| Depth (in.) | 20.06 |
| Height (in.) | 8.25 |
| Width (in.) | 36 |
| Appliance Fit Width (in.) | 36 |
| Collection | NikolaTesla |
| Color Finish Name | Deep Black |
| ADA Compliant | No |
| ENERGY STAR Certified | No |
| Number of Elements/Burners | 4 |
| Cut Out Depth | 19.38 |
| Cut Out Width | 31.75 |
| Downdraft Ventilation | Yes |
| Width (cm) | 91.44 |
| Height (cm.) | 20.96 |
| Depth (cm.) | 50.95 |
| Cut Out Depth Centimeter | 49.23 |
| Voltage | 208/240 |
| Frequency | 60 |
| Cut Out Width Centimeter | 80.65 |
| Cooktop Features | Bridge Element, Pan Presence Sensor |
| Cooktop Surface Style | Glass-Top |
| Cooktop Surface | Ceramic Glass |
Additional Attributes: | |
Range Hood/ Ventilation: | |
| Controls | Slider Touch Control 3S + Booster Ventilation |
| Heating Level | 9 Levels + Booster |
| Installation Type | Ducted Out or Recirculating |
| Blower speed 1 | 160 CFM |
| Blower speed 2 | 250 CFM |
| Blower speed 3 | 350 CFM |
| Blower speed 4 | 400 CFM (Booster) |
| Noise (sones) | Min: 2.2, Max: 5 |
| Filter Specifications | 6 Layer Anodized Aluminum Mesh Grease Filter |
| Electrical | 240V - 7.8kW at 32.5 Amps; 208V - 7.1kW at 34.1 Amps |
Cooking Zones: | |
| Cooking Zones | 4 (2,1 - 3,7kW) - 7,1 x 7,9 inches |
